Commercial tunnel type microwave fruit and vegetable LD oven
Brief introduction
1. Fast drying, uniform drying, save time
2. Easy to control, saftey, operation temperature can be adjustable
3. Mildew proofing, drying and sterilization at the same time
4. High efficient, loss enerLD less, save enerLD
5. CE certificate
Mainly application
This equipment are widely used for drying and sterilizing granular, flakes or colloidal form foods, nutritional health products, grain, agricultural and sideline products(rice, cornmeal), bamboo shoot, tea(wild chrysanthemum flower, broadleaf holly leaf, lotus leaf, green tea, black tea, puer tea), ginseng, mushroom, agaric, ganoderma, vegetables and fruits(spinach, carrot, parsley, onion, mango slice, apple slice, lemon slice, kiwi slice, banana slice etc.), preserved fruits, red jujube, non-fried(oil saving) instant noodles, noodles, cookie, biscuit, rice powder noodles, chicken jerky, beef jerky, preserved meat, dried fish, seafood(seaweed, sea cucumber, laver, kelp, sardine, shrimp, abalone etc.), pickles, spices(pepper powder, Chicken essence, beef essence, pork essence, yeast extract, seafood extract, seafood soup essence, seafood soup powder, spareribs soup pure, spareribs soup powder, spice, chili powder, ginger powder, garlic powder, aniseed, cinnamon, angelica, cumin, cassia bark, fennel etc.), egg yolk powder, jam, a variety of small packaging and pet food mildew sterilization preservation.
Microwave machine operating principle
Microwave is a sort of electromagnetic wave which frequency is 300MHz to 300GHz .The water molecule in medium materials is polar molecule,under the effect of the rapid change of electromagnetic field,its polarity orientation will alter with the changes of the external electric field with the high-speed,causing the movement and friction of molecule.
So that the microwave field enerLD can be converted to heat enerLD in medium to rise the temperature of materials.accomplishing heating ,puffing and a series of physical and chemical processes.
Microwave drying and sterilization features
1, Fast drying, uniform drying.
Microwave heating is completely different with traditional heating mode. It makes heating medium become heater, do not need heat transfer process. Although thermal conductivity is poor materials, also can achieve heating temperature in a very short time.
2,Save enerLD and efficiency, loss enerLD less.
Because materials contain water absorb microwave easily and fever, so in addition to a small amount of transmission loss outside, almost no other loss, so high thermal efficiency, save enerLD.
3, Heating even.
No matter how shape of each part of the body, microwave heating all can make the object and evenly infiltration and electromagnetic wave list to produce the heat. So heating good uniformity, won't appear the endogenous phenomenon focal.
4, Mould proof, sterilization, fresh.
Microwave heating has thermal and biological effect, can sterilize and mould proof in low temperature.Due to heating rapidly, the time is short, can maximum limit save material activity and the vitamin original color and lustre and nutrition of food.
5, Craft is advanced, control easily.
Microwave heating just have the basic conditions of water, electricity, as long as control power, can realize microwave heating or terminate immediately, use microwave equipment can process automation control of heating process and heating process specification.
6, Covers less area, safety and harmless.
Because microwave can be controlled in made of metal heating indoor and wave, so microwave leak is few, no radiation hazards and harmful gases, do not produce the waste heat and dust pollution; Neither polluting food, also do not pollute the environment.
Design features of machine
1.Transmission System:
a. Speed of Conveying belt is adjustable.
In the transmission system, it applies frequency-converting control of speed, worm gear reducer.
b. The conveyor belt is Teflon Belt,special for microwave.
c. The deviation of belt is adjusted with Hand-movement.
2. The body of the Tunnel
a.The body of the microwave tunnel is made of Stainless Steel. In side there is one set of humidity extraction system to extract the humidity after heating.
b. To be safe, there is Automatic Power-off device while open the door of the machine.
c. The protecting case of Magnetic-pipe and transformer is made of stainless steel. On top there is one set of Heat extraction system to extract the heat enerLD generated by
working of machine.
d.The frame of machine is made of Stainless Steel pipe ,others is made of cold-rolled sheet painted.
e.One set of infrared thermometric is installed at the outlet of the tunnel to measure the temperature.
3.The controlling system
a. On the outside panel there are frequency converting speed controller, emergency stop button, Start, Stop buttons,
b. All the controlling components will be installed into one controlling box, which is at the entrance of the machine.
c.Ordinary button control system,.
d.The microwave power can be adjusted by choosing in the display text.
e. Every microwave source is an independent unit.If one is broken, the machine will not be prevented from running.
f. Every magnetron has an overheating protection device.
The technical parameter of JN-40 microwave drying and sterilization machine
Power supply |
380V±10% 50HZ±1% three-phase five-wire |
|
Microwave Output Frequency
|
2450±50MHz |
Microwave input apparent power |
56KVA |
Microwave output power |
40KW |
Microwave power adjustment range |
0-40KW(adjustable) |
Ambient temperature |
-5-40°C |
Dehydrate |
40-48kg/h |
Relative humidity |
80%, Surrounding environment:no corrosive gas, conductive dust and explosive gas |
Overall dimension(L*W*H) |
10500*1440*1750mm |
Transmission speed |
0-10m/min(adjustable) |
HeigLD of the inlet and outlet |
60 mm |
Microwave leak |
accord with a country GB10436-89 standards( |
Equipment safety |
accord with GB-5226Electrical safety standard accord with a country GB16798-1997 Food machinery health security index |
NOTE:We can specially design the machine according to your production's features.
JINAN Microwave machinery equipment Co.,Ltd.
Welcome to contact with me
