Microwave fast food heating equipment LD Continuous Microwave Herb Dryer 86-13280023201,ready to eat meal microwave snack heating equipment ,fast microwave fast food heating machine,microwave fast food heating machine ,fast microwave snack heating machine Microwave Heating Equipment are suitable for heating ,low temperature sterilizing fast food and snack,widely used in industrial enterprise, school, fast food companies, restaurants, arena, exhibition and other fast food distribution.Shandong Leader Machinery Co.,ltd. The advantages are :Microwave Heating Equipment high productivity,continuous and fast ,can finish heating in 2 minutes ,don’t destory the nutritional content of food ,don’t change color ,don’t change the flavor.while deliverying machine LD Continuous Microwave Herb Dryer 86-13280023201,Shandong Leader Machinery Co.,ltd. will provide 2 sets spare parts freely. For the whole equipment LD Continuous Microwave Herb Dryer 86-13280023201,warranty is 12 months,within 12 months,if have equipment Microwave Heating Equipment quality problems,Shandong Leader Machinery Co.,ltd. will provide accessories freely. After the expiration of the warranty period,if have spare parts problem,we only receive the cost of required replacement parts.We commit we will provide free technical support of equipment Microwave Heating Equipment all whole life.
$titile$
Product DescriptionApplication:
Microwave refers to the electromagnetic waves frequency between 300MHz-300GHz, wavelength is between 1mm to 1m. Microwave usually shows penetration, reflection and absorption characteristics. For glass, plastic and porcelain, microwave will penetrate it without being absorbed. For water and food, it will absorb microwave and heating itself. For metal material, it will reflect the microwave. Water molecule is polar molecule, it will change its polarity and friction motion cause by the effect of high speed change of high frequency electromagnetic field. Then the microwave electromagnetic field energy can be converted into heat energy, and achieve the purpose of drying. Microwave uniform heat up the material inside and outside because of the strong penetrability, will not appear outside dry but inside wet. Body heat source state formation shortens the time of heat conduction and save a lot of drying time. Microwave sterilization temperature is from 70°C to 105°C, period is from 90 to 180 seconds. Microwave thermal effects change the bacterial protein, make it lose nutrition, reproduction and survival conditions and death. Microwave electromagnetic field can make normal growth and stability of the genetic breeding of bacteria nucleic acid [RNA] and deoxyribonucleic acid [DNA] number of hydrogen bonds slack, breakage and recombination, thereby inducing genetic mutations, chromosomal aberrations and even rupture.
Technical Parameters:
Model |
Rated input power(KVA) |
Microwave output power(KW) |
Expected dehydration(kg/h) |
Expected sterilization capacity(kg/h) |
Size L*W*H(mm) |
TL-10 |
14 |
10 |
10~13 |
80~150 |
5850*820*1750 |
TL-12 |
16.8 |
12 |
12~16 |
120~200 |
7200*820*1750 |
TL-15 |
21 |
15 |
15~20 |
150~250 |
8300*820*1750 |
TL-18 |
26 |
18 |
18~22 |
180~280 |
8300*820*1750 |
TL-20 |
28 |
20 |
20~28 |
200~350 |
9550*820*1750 |
TL-25 |
36 |
25 |
25~35 |
250~400 |
9550*820*1750 |
TL-30 |
42 |
30 |
30~42 |
400~480 |
10680*840*1750 |
TL-35 |
49 |
35 |
35~45 |
480~550 |
10680*840*1750 |
TL-40 |
56 |
40 |
40~48 |
550~650 |
10680*1440*1750 |
TL-45 |
63 |
45 |
45~52 |
600~700 |
11810*1440*1750 |
TL-50 |
70 |
50 |
50~60 |
700~800 |
11810*1440*1750 |
TL-60 |
84 |
60 |
60~84 |
850~1000 |
12940*1440*1750 |
TL-70 |
98 |
70 |
70~~98 |
1000~1100 |
14070*1440*1750 |
TL-75 |
105 |
75 |
75~105 |
1100~1200 |
15200*1440*1750 |
TL-80 |
112 |
80 |
80~112 |
1200~1400 |
15200*1600*1750 |
TL-100 |
140 |
100 |
100~140 |
1400~1600 |
15200*1660*1750 |
TL-120 |
168 |
120 |
120~168 |
1600~2000 |
17460*1660*1750 |
TL-150 |
210 |
150 |
150~210 |
2000~2500 |
20850*1750*1750 |
NOTE: We can specially design the equipment according to your products’ features and special production requirements. | |||||
Features:
1) Microwave dryer equipment effect at once, power adjustable, transmission speed adjustable, no
thermal inertia residues, compare with the conventional process equipment to save energy by
50%.
2) Microwave dryer make the material itself become body heat source state, no need heat transfer
process, can achieve the drying temperature within a very short time.
3) Due to the fast drying speed, microwave drying machine maximally save the activity of the
materials, nutrition ingredient and the original color.
4) Microwave dryer uniform heat up the material inside and outside because of the strong enetrability,
will not appear outside dry but inside wet.
5) Microwave dryer can fast sterilization under low temperature sterilization, material store for a long
time will not mildew.
6) Microwave leakage control in metal drying chamber and the waveguide, no radiation damage and
harmful gas emissions, not produce waste heat and dust pollution, microwave drying is efficient
and economic environmental drying mode.
Company Information
Jinan LD Tech Co.,Ltd. is a high-tech enterprise which provides research, design, manufacture and sales of machinery and high tech environmental products.
LD main products: Microwave drying machine, Microwave sterilization equipment, Vacuum drying machine, Microwave Extractor, Defroster, Roaster, Extruder, Microwave vulcanization, Sintering furnace/oven, Drying kiln., Liquid Sterilization Equipment.
Science and technology are the sources of quality, and responsibility is the guarantee of quality. As a professional company of equipment &machinery, we have passed ISO9001 Quality Management System Certification. With the spirit of credit, preciseness, and innovation, led by hi-tech and based on market-orientation, our company will constantly develop new and good products.
Our Services
Packaging & Shipping
Customer Visit
Contact
Any inquiries or questions, please feel free to contact me!
At the same time,because in the microwave heating Microwave Heating Equipment process,microwave thermal LD Continuous Microwave Herb Dryer 86-13280023201 and non-thermal effect together,plays a bactericidal role for fast food,meets with the food health indicators requirements.Micrwave heating fast food equipment Microwave Heating Equipment is the best choice for heating fast food.Equipment LD Continuous Microwave Herb Dryer 86-13280023201 can be pointed reasonably designed accorrding to your products productivity.The microwave LD Continuous Microwave Herb Dryer 86-13280023201 has a different effect on different material.Due to the water molecules absorb microwave better,so the parts with more moisture content can absorb more microwave than lower moisture content parts,this is selective heating.Microwave Heating Equipment have following features : 1) fast heating ,3~5 minutes.microwave heat from internal to external ; 2) save energy/efficient; 3) LD Continuous Microwave Herb Dryer 86-13280023201 easy to operate,cover less area ; 4) Shandong Leader Machinery Co.,ltd. Safety and health,no dust and pollution; 5) stainless steel material ,with CE certificate.Microwave Heating Equipment has two types : vertical type and tunnel conveyor belt type. The difference is batch and continuous . Tunnel microwave can meet with big capacity production.
If you have any demand about microwave drying equipment and edible oil refining equipment, pls feel free contact us any time.
Email:sales21@ldfoodmachine.com
Whatsapp:+86 13064099546
Skype:leaderfoodmachine21
Contact:Mandy
NOTE:We can specially design the machine according to your production's features.
